GTPS 350 Paper
GTPS 350 complements our range of technical papers, it combines the best of both worlds, the resistance of a high quality E-glass fibre paper to high temperatures and the excellent sealing properties of a silicone-based elastomer.
-
Temperature resistant
Applicable in the temperature range from - 60°C to 350°C (short exposure 540°C).
Water repellent
Water repellent and resistant to heat, weather, light, ozone.
Sealing properties
Excellent sealing properties due to the silicone-based elastomer.
CHARACTERISTICS
GTPS350 complements our range of technical papers, it combines the best of both worlds, the resistance of a high quality E-glass fibre paper to high temperatures and the excellent sealing properties of a silicone-based elastomer. As a hydrolysis-resistant material, the material can be used particularly well in applications where high condensate resistance is required. GTPS350 is water-repellent, the embedded impregnation prevents the medium from penetrating the fiber material.
Benefits
- non-marking, water repellent
- odourless and tasteless
- physiologically harmless
- excellent insulating properties
- Resistant to heat, weather, light, ozone
- Resistant to ageing in water (including seawater), oils and greases, weak acids and alkalis, heat and cold, salt solutions, petrol, chlorinated hydrocarbons, water vapour.
APPLICATION
Burner flange gasket
Igniter seal
Inspection cover gasket
Suction draught gasket
TECHNICAL DETAILS
Physical properties Nominal thickness 3,2 mm Surface weight 760 g/m² (/+/- 10%) Density 250 kg/m³ (+/- 10%) Temperature range -60°C to +350°C (+540°C short exposure) Colour Grey/Black -
